Dehumidification Dryer

Gaoxin's Dehumidification Dryer is a key material handling equipment in the plastics and chemical industries, specializing in the dehumidification and drying of raw materials in high-humidity environments. Combining a dehumidification system with hot air drying technology, it can deeply remove moisture from raw materials, preventing problems such as bubbles and cracking during subsequent processing. The equipment boasts high humidity control precision and is adaptable to a variety of materials, including granules and powders. It can also be integrated with molding equipment to provide low-moisture raw materials for production, helping to ensure stable product quality. It is particularly suitable for humidity-sensitive processing scenarios.

Send Inquiry

Product Description

Uses of dehumidification dryer:

In addition to mainly targeting engineering plastics with strong hygroscopicity, it solves the problems caused by poor drying of products: bubbles, silver streaks, cracks, flow marks, poor transparency and other poor quality problems; engineering plastics such as: PA, PET, PU , TPU, PC, PBT, CA, etc. are highly hygroscopic. Since water penetrates into the interior of the plastic pellets, traditional dryers cannot completely dry them.

Principle of dehumidification dryer:

Paired with a hot air hopper dryer to perform high-efficiency dehumidification and drying operations.

Effectively lower the dew point of drying air to below -40℃ while controlling heat.

Only by blowing it over the surface of the moisture-containing plastic particles can the moisture content be reduced to less than 0.02% before molding.

The honeycomb dehumidifier fully dehumidifies the air in a closed circulation system and quickly completely separates the moisture in the plastic particles to achieve the dehumidification and drying effect.

Three-in-one core technology

What Occasions Do You Need Me For?

Engineering plastics such as PA, PET, PU, TPU, PC, PBT, and CA are highly hygroscopic materials. Because moisture seeps into the plastic pellets, traditional hot air dryers are unable to completely dry them. A three-in-one dehumidifying dryer fully dehumidifies and heats the air in a closed circulation system. The dry air quickly extracts moisture from the plastic pellets, achieving the desired dehumidification and drying effect.

Dehumidification dryer---multiple models available

"The honeycomb rotor, with its powerful dehumidification properties, absorbs moisture from the air,

creating a low-dew-point, highly absorbent airflow for dehumidifying and drying raw materials."

The honeycomb rotor design maintains stable temperatures below -40°C dew point, ensuring high-quality and stable molded plastic products. The entire series features a standard P.I.D. temperature control system; the control system is equipped with an LED LCD display and automated control.

Honeycomb rotor single dehumidification
Three machines in one dehumidification
Dehumidification + drying + pumping
Large models available

Three-in-one dehumidifier

This three-in-one dehumidifier combines dehumidification, drying, and feeding functions in one unit.

It's particularly suitable for applications requiring high automation and compact space. The entire machine utilizes PLC control for simple operation.

A dew point meter is also available as an option for monitoring the dehumidification performance. Incorporating European design principles, the machine boasts a more aesthetically pleasing appearance, more stable performance, and lower energy consumption.

Technical parameters of dehumidification dryer (three machines in one)

Model		GX-90L/80A	GX-120L/80A	GX-160L/80A	GX-230L/80A	GX-300L/80A	GX-450L/80A
Drying hopper	Capacity	90	120	160	230	300	450
Drying hopper	Insulation Materials	Fiberglass insulation + exterior panels
Average dry air dew point		-40℃
Drying temperature		80~160
Drying air volume		80	80	130	160	220	300
Drying fan		0.75	0.75	1.1	1.5	2.2	3
Regeneration fan		0.25	0.25	0.25	0.55	0.55	0.75
Dry electric heat		3.9	6	6	7.2	12	15
Regenerative electric heat		3.9	3.9	3.9	5.4	5.4	7.2
Pipe diameter	Dry	51	51	51	63	63	76
	Cool down	3/4″
	Regeneration	38	38	38	51	51	63
Feeding fan		1.1	1.1	1.1	1.5	1.5	1.5
Conveying distance	One feed	10
Conveying distance	Secondary feeding	10
Feeding piping		1.5
Electric eye hopper		6	6	12	12	12	12
Vacuum hopper		6	6	12	12	12	12
Dimensions		180×100×87	180×100×87	180×100×87	225×165×125	225×165×125	290×150×130
Net weight		310	340	360	420	550	600

A corner of the dehumidification dryer workshop

Single-unit dehumidification dryer
Integrated dehumidification dryer
Energy-saving drying-automatic extraction system
Dehumidification and drying-energy-saving dryer
